Model NO.
16x4.5F 16X5.5F 16X6 16X8 16.5X8.25
Wheel Accessories
Wheel Spoke
Certification
ISO, VIA, CE, TUV, ISO/Ts16949/DOT/TUV
Trailer Wheels
8X2.5 8X3.75 8X5.375 8X7.0 8X8.5
Car Trailer Wheel
14X5.5j 14X6j 15X6j 15X7j 16X6j 16X7j
Production Capacity
2000PCS/Day
| ATV Wheel Series Specification |
| Code |
Size |
Bolt Hole Circle |
Center Hole |
ET |
Tire |
| CC0645B09 | 6×4.5 | 3-ø8.5-ON-ø80/90 | ø55 | 0 | 15×6-6 |
| CC0755B01 | 7×5.5 | 3-ø8.5-ON-ø80/90 | ø55 | 0 | 18×7-7 |
| CC0855B01 | 8×5.5 | 4-ø10.5-ON-ø110/100 | ø60/ø90 | 12.7 | 19×7-8 |
| CC0807B01 | 8×7 | 4-ø10.5-ON-ø110/100 | ø60/ø90 | 0 | 18×9.5-8 |
| CC1055A01 | 10×5.5 | 4-ø10-ON-ø110 | ø60 | 25 | 21×7-10 |
| CC1085A02 | 10×8.5 | 4-ø12-ON-ø110 | ø90 | 20 | 22×11-10 |
| CC1080A01 | 10×8 | 4-ø12-ON-ø101.6 | ø60 | 20 | 20×10-10 |
| CC1275A01 | 12×7.5 | 4-ø12.5-ON-ø101.6 | ø60 | 38 | 25×10-12 |
| CC1206A02 | 12×6 | 4-ø12.5-ON-ø110 | ø60 | 30 | 24×9-12 |
| CC1275A02 | 12×7.5 | 4-ø12.5-ON-ø110 | ø60 | 38 | 25×10-12 |
| CC1275A03 | 12×7.5 | 4-ø12.5-ON-ø136 | ø60 | 38 | 25×10-12 |
| CC1206A04 | 12×6 | 4-ø12.5-ON-ø114.3 | ø60 | 30 | 24×9-12 |
| CC1275A04 | 12×7.5 | 4-ø12.5-ON-ø114.3 | ø60 | 38 | 25×10-12 |
An Overview of Popular ATV Steel Wheel Models
All-Terrain Vehicle (ATV) enthusiasts often prioritize durability, affordability, and functionality when selecting components, especially wheels. Steel wheels remain a cornerstone for utility, work, and rugged recreational use due to their exceptional strength, cost-effectiveness, and repairability.
The Enduring Appeal of Steel Wheels
- Exceptional Durability and Impact Resistance: Steel is inherently tough and malleable. Unlike aluminum, steel wheels are more likely to bend than crack under severe impact, allowing for field repairs.
- Cost-Effectiveness: Generally significantly less expensive than aluminum counterparts, making them an attractive option for budget-conscious buyers and utility work.
- Strength for Heavy-Duty Applications: Robust construction ideal for hauling heavy loads, plowing snow, and navigating rocky environments.
- Simplicity and Reliability: Simple, proven design offers long-term reliability without complexity.
Frequently Asked Questions
Q1: What are the primary advantages of steel wheels over aluminum alloy?
Steel wheels offer exceptional durability and impact resistance. They bend instead of cracking under impact, are much more cost-effective, and are ideal for heavy-duty utility tasks where function is prioritized over aesthetics.
Q2: What are the main disadvantages of steel wheels?
The main trade-offs include higher weight (unsprung mass), potential for corrosion if the finish is damaged, limited design options compared to alloy wheels, and slightly lower heat dissipation from brakes.
Q3: What specifications are critical when buying ATV steel wheels?
Critical specifications include the Bolt Pattern (PCD), Wheel Size (Diameter and Width), Offset (Positive or Negative), and the Center Bore diameter. These must match your ATV's hub requirements for safe fitment.
Q4: Can steel wheels be used with radial tires for better performance?
Yes. A radial tire on a steel wheel still offers improved handling and a smoother ride. While the heavier steel wheel might slightly mute these gains compared to aluminum, the primary benefits of the tire upgrade will still be realized.
Q5: How should I maintain my steel wheels?
Clean them regularly to remove mud and road salt, inspect the powder coat for chips or scratches and touch up bare metal with paint immediately, and periodically ensure lug nuts are torqued to specification.
Q6: Who is the ideal candidate for choosing steel wheels?
Steel wheels are perfect for utility and work ATV owners, budget-conscious riders, those navigating extreme rocky terrain, and anyone who values the ability to perform field repairs in remote areas.
